Article number 63-002140-053
| Article number | 63-002140-053 |
| Brand | Apator |
| Order quantity per | 1 |
| Type of kWh meter | 0 |
| Display | LCD |
| Mounting method | Surface mounted |
| Version of kWh meter | Direct connected |
| Phase | 1 |
| Communication module: interface module | 0 |
| Communication module: interface module | RS485 |
| Safety characteristics: rated peak withstand voltage | 4 kV as per EN 62052-31 |
| Energy registers | 4 tariff register |
| Accuracy class reactive energy | CI. 2 according to EN 62053-23 |
| CE marking | Yes |
| MID approved | Yes |
| Accuracy class active energy | CI. B according to EN 50470-1, -3 |
| Height | 215 mm |
| Width | 126 mm |
| Length | 43.7 mm |
| Supply voltage | 230 V |
| AC/DC | AC (alternating current) |
| Protection class | IP53 |
| EMC characteristics: surge voltage | 6 kV, pulse 1.2/50 µs, 500 Ω |
| Power consumption per phase: voltage circuit | <1,5 VA/<1,0 W |
| Frequency | 50 Hz |
| Maximum operating temperature | 55 °C |
| Minimum operating temperature | -25 °C |
| Pulse values LED | 5000/kWh |
| Real time clock: running accuracy | <0.5 s/24 H at 23°C |
| Current | 5 (60) A |
| Measuring types active energy | +A, -A |
| Voltage | 230 V |
