Article number 690413001
Robust, corrosion-resistant, self-supporting chassis Impact-resistant ABS housing Triplex plunger pump with brass pump head High-quality stainless steel plungers Stainless steel valves Etronic I control technology: Start-stop system with delay switch-off Complete switch-off after 20 minutes Two-motor system, independent for HP pump and burner Unloader safety valve with infinitely variable pressure and flow rate regulation Two large rubber wheels with castor, suitable for rough terrain with patented wheel brake and steering control Storage space for all accessories Integrated 22 liter fuel tank Robust on/off rotary switch 8 meter power cable Removable ergonomic push handle Hose reel for high-pressure hose Cable reel for connection cable
| Article number | 690413001 |
| Brand | Ehrle |
| Drive | 230 volts |
| Packing unit | 1 |
| Order quantity per | 1 |
| Maximum working pressure | 10 l/min |
| Commodity code | 84243001 |
| Manufacturer country | DE |
| Type of high pressure cleaner | Hot water |
| 45°C |
| Equipment | Trigger gun standard with quick coupling |
| Equipment | Lance with nozzle protection |
| Equipment | Fuel tank |
| Equipment | Flat spray nozzle |
| Safeguards | Start-stop system with cut-off delay |
| Equipment | Hose drum |
| Equipment | 15m high pressure hose DN08 |
| Range | Etronic I |
| Safeguards | Total shutdown after 20 minutes |
| Position | Mobile |
| Safeguards | 16A slow |
| Height | 1020 mm |
| Width | 735 mm |
| Length | 1070 mm |
| Length connection cable | 8 m |
| Length hose | 15 m |
| Product weight | 118 kg |
| Minimum water output | 5 l/min |
| Minimum working pressure | 30 Bar |
| Maximum working pressure | 120 Bar |
| Frequency of power supply | 50 Hz |
| Overpressure | 140 Bar |
| Fuel Consumption at max heating output | 5 kg/h |
| Heat generation | Diesel |
| Hot water output (max) | 98 °C |
| Hot water output (min) | 30 °C |
| Power consumption | 2.4 kilowatts |
| Maximum water output | 10 L p/m |
| Maximum working pressure | 120 Bar |
| Revolutions per minute (RPM) | 2800 rpm |
| 045 | |
| Current capacity of power supply | 12 amp |
| Heating output | 46 kilowatts |
| Fuel tank capacity | 22 liters |
| Supply voltage | 230 Volts |
