Article number 690156201
Robust, corrosion-resistant and self-supporting stainless steel chassis Suitable for floor mounting Triplex plunger pump with chrome-nickel pump head (resistant to hot water) Resistant to hot water up to 80°C High-quality ceramic plungers Stainless steel valves Leakage return system Booster pump for supplying the HD pump (to prevent cavitation) Automatic on and off control of the HD pump via PLC control Total switch-off adjustable from 5 to 600 minutes, with leak detection Unloader safety valve for device monitoring Pressureless lines in standby mode Robust on/off rotary switch - lockable
| Article number | 690156201 |
| Brand | Ehrle |
| Drive | 400 volts |
| Maximum working pressure | 45 l/min |
| Commodity code | 84243008 |
| Manufacturer country | DE |
| Order quantity per | 1 |
| Type of high pressure cleaner | Cold water |
| Packing unit | 1 |
| 80°C |
| Safeguards | Leak detection |
| Safeguards | Safety valve |
| Equipment | Water storage tank |
| Equipment | Siemens S7-1200 PLC controls |
| Equipment | Pressureless pipes in stand-by mode |
| Equipment | Maintenance interval display |
| Equipment | Booster pump for charging the high-pressure pumps |
| Equipment | Automatic switch on and off high pressure pumps |
| Equipment | Automatic stand-by operation |
| Equipment | 7'' touch screen monitor |
| Safeguards | 3x50A slow |
| Range | KSM |
| Position | Fixed |
| Safeguards | total-switch-off between 5-600min - adjustable |
| Safeguards | Lockable |
| Height | 2090 mm |
| Width | 800 mm |
| Length | 1130 mm |
| Length connection cable | 5 m |
| Product weight | 573 kg |
| Minimum water output | 15 l/min |
| Minimum working pressure | 30 Bar |
| Maximum working pressure | 180 Bar |
| Frequency of power supply | 50 Hz |
| Overpressure | 200 Bar |
| Supply voltage | 400 Volts |
| Revolutions per minute (RPM) | 1400 rpm |
| Maximum water output | 45 L p/m |
| Maximum working pressure | 180 Bar |
| 3x050 | |
| Current capacity of power supply | 38 amp |
| Power consumption | 21 kilowatts |
