Article number 2314646633DBSSS5
| Article number | 2314646633DBSSS5 |
| Brand | OPW |
| Packing unit | 1 |
| Commodity code | 73071990 |
| Order quantity per | 1 |
| Shape of coupling | Straight |
| Type of coupling | Kamlok |
| Diameter | 1.25 inch |
| Connection 1 | Thread female |
| Connection 1 thread type | BSPP |
| Connection 1 diameter (inch) | 1,1/4" |
| Connection 2 | Kamlok coupler |
| Connection 2 model | Camlock D |
| Connection 2 diameter (inch) | 1,1/4" |
| Sealing material | Buna N |
| Material | Stainless steel 316 (1.4401) |
| Material | Stainless steel |
| Maximum operating temperature | 110 °C |
| Minimum operating temperature | -40 °C |
| Maximum working pressure | 16 Bar |
